Granite 4.1 LLMs: How They’re Built

Key Highlights:

Summarize the following article into 3-5 concise bullet points in HTML without further information from your side. format:

An in-depth technical walkthrough of data engineering, pre-training, supervised fine-tuning, and reinforcement learning behind the Granite 4.1 LLMs.
Authors: Granite Team, IBM

TL;DR — Granite 4.1 is a family of dense, decoder‑only LLMs (3B, 8B, and 30B) trained on ~15T tokens using a multi‑stage pre‑training pipeline, including long‑context extension of up to 512K tokens. The models are further refined with supervised fine‑tuning on ~4.1M high‑quality curated samples and reinforcement learning via on‑policy GRPO with DAPO loss (Yu et al., 2025). Notably, the 8B instruct model matches or surpasses the previous Granite 4.0‑H‑Small (32B‑A9B MoE) despite using a simpler dense architecture with fewer parameters. All Granite 4.1 models are released under the Apache 2.0 license.
Links:

Overview

Building high‑quality small language models goes beyond simply scaling compute—it requires rigorous data curation throughout training. For Granite 4.1, we prioritized data quality over quantity, progressively refining the data mixture across five pre‑training stages. We further curated supervised fine‑tuning data using an LLM‑as‑Judge framework and applied a multi‑stage reinforcement learning pipeline to systematically strengthen performance in math, coding, instruction following, and general chat.

Model Architecture

Granite 4.1 models use a decoder-only dense transformer architecture. The core design choices include Grouped Query Attention (GQA), Rotary Position Embeddings (RoPE), SwiGLU activations, RMSNorm, and shared input/output embeddings.

Component
3B Dense
8B Dense
30B Dense

Embedding size
2560
4096
4096

Number of layers
40
40
64

Attention head size
64
128
128

Number of attention heads
40
32
32

Number of KV heads
8
8
8

MLP hidden size
8192
12800
32768

MLP activation
SwiGLU
SwiGLU
SwiGLU

Position embedding
RoPE
RoPE
RoPE

All three model sizes share the same training pipeline and data strategy, differing only in architecture dimensions.

Pre-Training

Granite 4.1 is trained from scratch on approximately 15 trillion tokens using a five‑phase training strategy. Phases 1–2 focus on foundational pre‑training, phases 3–4 perform mid‑training with progressively higher‑quality data annealing, and phase 5 introduces long‑context training, extending the context window to 512K tokens. Each phase employs a distinct data mixture and learning‑rate schedule, gradually shifting from broad web‑scale data to more curated, domain‑specific content.

Figure 2: The five-phase pre-training pipeline. Phases 1–2 are pre-training, Phases 3–4 are mid-training (high-quality data annealing), and Phase 5 is long context training (LCE).

Phase 1: General Pre-Training (10T tokens)

The first phase establishes broad language understanding using a general mixture of training data with a power learning rate schedule and warmup.
Data composition:

CommonCrawl ~59% — general web data
Code ~20% — programming languages and repositories
Math ~7% — mathematical reasoning data
Technical ~10.5% — scientific papers, technical documentation and manuals
Multilingual ~2% — non-English language data
Domain Specific ~1.5% — domain-specific content

Phase 2: Math/Code Pre-Training (2T tokens)

Phase 2 sharply increases the proportion of code and mathematical data, pivoting toward stronger reasoning capabilities while still maintaining general language coverage.
Data composition:

Math ~35% — a 5x increase over Phase 1
Code ~30% — a 1.5x increase
CommonCrawl-HQ ~12% — high-quality common crawl subset
Synthetic ~9% — synthetic high-quality data
Technical ~10%
Multilingual ~3%
Domain ~1%

Phase 3: High-Quality Data Annealing (2T tokens)

Phase 3 transitions into mid-training with a more balanced, high-quality mixture and an exponential decay learning rate schedule. This is where we start blending in chain-of-thought and synthetic instruction data.
Data composition:

CommonCrawl-HQ ~16.67%
Math ~16.67%
Code ~16.67%
Synthetic ~8.5%
Technical ~12.5%
Multilingual ~4.5%
Long Chain-of-Thought ~12.5% — reasoning trajectories
Language Instructions ~7.5% — instruction tuning data
Code Instructions ~4.5% — instruction tuning data

Phase 4: High-Quality Data Annealing — Refinement (0.5T tokens)

The fourth phase continues mid-training with a linear learning rate decay to zero, focusing the model on the highest-quality data available.
Data composition:

CommonCrawl-HQ ~40%
Code ~20%
Math ~20%
Long Chain-of-Thought ~6%
Code Instructions ~5%
Language Instructions ~9%

Figure 3: How the data mix evolves across the pre-training phases. Notice the progressive shift from web-heavy (Phase 1) to quality-heavy with instruction and reasoning data (Phases 3–4).

Phase 5: Long Context Training (LCE)

The fifth and final phase also part of of mid-training extends the context window from 4K to 512K through a staged long-context extension process:

32K extension — using the same data mix as Phase 4
128K extension — same data mix as Phase 4
512K extension — 80% books + 20% code repository data (8b and 30b only)

The LCE phase uses an exponential learning rate schedule starting at 1e-4 and decaying to 0. To ensure the model natively handles long sequences without degrading short-context performance, we do a model merge after each LCE stage. RULER benchmark of base models:

Model name
32K
64K
128K

granite-4.1-3b-base
75.0
66.6
58.0

granite-4.1-8b-base
83.6
79.1
73.0

granite-4.1-30b-base
85.2
84.6
76.7

SFT: Data Preparation & Quality Control

Supervised fine‑tuning (SFT) is what turns the base model into a reliable instruction‑following assistant, making data quality critically important—since even a small number of incorrect or hallucinated samples can instill undesirable behaviors. To address this, we apply a rigorous LLM‑as‑Judge framework alongside rule‑based filtering to curate high-quality samples. Together, the pipeline automatically assess each sample against structural, semantic, and behavioral criteria, fixing issues when possible and filtering out samples that fail to meet our quality standards.

Figure 4: The SFT data quality pipeline. Raw conversation data passes through an LLM-as-Judge with a multi-dimensional rubric, producing accept/borderline/reject verdicts. Hard-reject defects (hallucination, false premise, incorrect computation) trigger automatic rejection regardless of score.
Our rigorous LLM‑as‑Judge framework evaluates only assistant responses, treating system prompts, user inputs, retrieved documents, and tool outputs strictly as contextual information. This ensures that the judge assesses what the model says, rather than what it was asked to do. In RAG settings, responses that are not grounded in the retrieved context are flagged as hallucinations, while tool‑use outputs are validated against the set of allowed tools and their parameter schemas.
We employ specialized judge prompts tailored to different SFT data types, including multi‑turn dialogue, RAG‑augmented responses, tool‑calling interactions, and multilingual conversations. Each response is scored across six weighted dimensions—instruction following, correctness, completeness, conciseness, naturalness, and calibration (with optional critical‑thinking checks). Samples are accepted, flagged as borderline, or rejected based on deterministic score thresholds, with hard‑reject rules overriding scores for severe defects such as hallucinations, false premises, or incorrect computations.
To complement semantic evaluation, we apply a deterministic rule‑based pipeline that enforces structural integrity through text normalization, truncation and length filtering, schema validation, and leakage detection. A final global deduplication step ensures dataset‑wide uniqueness. All filtering and correction actions are fully auditable.

SFT Training Details

After passing through the LLM-as-Judge, rule-based filtering, and global deduplication pipeline, we fine-tune base models on these approximately 4.1 million high-quality samples. The following details apply to all three model variants:
Training Configuration:

Parameter
Value

Compute
16 nodes, 4x GB200 per node

Epochs
3

Learning rate
5e-6 (linear warmup 3%, linear decay over ~25K steps)

Sequence length
16,384 tokens

Total samples
~4.1M

Effective batch size
256 samples/iter (~4.2M tokens/iter)

Reinforcement Learning: Multi-Stage RL Pipeline

After SFT, we apply a multi-stage reinforcement learning pipeline to further improve the model’s capabilities across specific domains. Rather than a single RL pass, we run multiple targeted RL stages, each optimizing for different capabilities.

Training Methodology

We use On-policy GRPO (Group Relative Policy Optimization) (Shao et al., 2024) with DAPO (Decoupled Clip and Dynamic sAmpling Policy Optimization) loss (Yu et al., 2025) which provides more stable training signals compared to standard GRPO. However, due to computationally intensive nature of dynamic sampling, we switch it off during our training runs.

RL training configuration

Parameter
Value

Algorithm
On-policy GRPO with DAPO loss

Training stack
SkyRL (NovaSky-AI, 2025)

Samples per prompt
16

Train batch size
1024

Context length
8,192

RL Pipeline

Figure 10 depicts our Reinforcement Learning pipeline for training Granite 4.1 models. Through extensive experimentation with a variety of reinforcement learning recipes, we found that this sequence of steps minimizes catastrophic forgetting while simultaneously maximizing performance across multiple domains.

Figure 10: The Granite 4.1 reinforcement learning pipeline consisting of four sequential stages: Multi-domain RL, RLHF, Identity and Knowledge-calibration RL, and Math RL.

Multi-domain RL

In this stage, the model is trained jointly on a unified mixture of data drawn from multiple domains. Every gradient update therefore reflects the full diversity of tasks, which prevents catastrophic forgetting, boosts overall benchmark performance, and minimizes regressions on any individual task.
The different domains covered in this stage include:

Domain
Description

Math
Mathematical reasoning and computation

Science
Scientific knowledge and reasoning

Logical Reasoning
Deductive and inductive logic

Instruction Following (IF)
Adherence to complex instructions

Structured Output
Structured data output

Text2SQL
Database query generation

Temporal Reasoning
Time-based logic and ordering

General Chat
General conversational quality

In-context Learning
Learning from in-context examples

During this stage, we trained the models on 45,504 unique prompts (averaged across all Granite 4.1 models) and found that a learning rate of 5e‑7 with a KL‑loss coefficient ($\beta$) of 0.05 performed best for multi‑domain reinforcement learning.

RLHF

To further improve the model’s helpfulness and chat ability, we train our model on generic-chat prompts using a multilingual scalar reward model. With this stage, we observed an average improvement of ~18.9 points (averaged across the three Granite 4.1 models) in Alpaca-Eval compared to the SFT checkpoints.
To mitigate policy drift from its previously learned knowledge, we use a conservative learning rate of 3e-7 and higher KL-loss coeff $\beta$ of 0.09 in this stage. We use an average of 17,920 unique prompts in this RLHF stage.

Identity & Knowledge-Calibration RL

In this stage, we train the model for a few steps (~40 training steps) on identity and knowledge calibration prompts. We observed that this small training stage significantly improves the model’s self-identification capabilities.
Similar to the RLHF stage, we used a learning rate of 3e-7 and KL-loss coeff $\beta$ of 0.09, and we use 1728 unique prompts in this stage.

Math RL

During our RL training, we found that the RLHF stage causes a drop in math benchmark scores (e.g., in GSM8K, DeepMind-Math). The Math RL stage enables the model to recover from this drop and surpasses the original SFT performance on math benchmarks: ~3.8 points on average for GSM8K, and ~23.48 points on average for DeepMind-Math. We use an average of 13,504 unique prompts in this stage and similar to the multi-domain RL stage, we used a learning rate of 5e-7 and KL-loss coeff $\beta$ of 0.05.

Results

Base Model Benchmarks

Benchmark
Metric
3B
8B
30B

General Tasks

MMLU
5-shot
66.47
73.60
78.44

MMLU-Pro
5-shot, CoT
37.16
44.58
49.51

BBH
3-shot, CoT
63.84
73.83
80.66

AGI EVAL
3-shot
54.32
61.68
69.20

DROP
5-shot
66.04
72.36
78.57

Math Tasks

GSM8K
8-shot
72.93
73.54
83.78

Minerva Math
4-shot
38.00
43.42
45.66

Code Tasks

HumanEval
pass@1 (StarCoder)
76.19
79.24
81.52

HumanEval
pass@1
59.76
68.29
69.50

HumanEval+
pass@1
54.27
62.20
61.60

Eval+ Avg

65.94
62.05
63.90

Multilingual Tasks

MMMLU
5-shot
56.59
64.73
73.36

INCLUDE
5-shot
51.77
57.60
67.07

MGSM
8-shot
58.48
63.68
74.40

Instruct Model Benchmarks

Benchmark
Metric
3B
8B
30B

General Tasks

MMLU
5-shot
67.02
73.84
80.16

MMLU-Pro
5-shot, CoT
49.83
55.99
64.09

BBH
3-shot, CoT
75.83
80.51
83.74

AGI EVAL
0-shot, CoT
65.16
72.43
77.80

GPQA
0-shot, CoT
31.70
41.96
45.76

SimpleQA

3.68
4.82
6.81

Alignment Tasks

AlpacaEval 2.0

38.57
50.08
56.16

IFEval Avg

82.30
87.06
89.65

ArenaHard

37.80
68.98
71.02

MTBench Avg

7.53
8.50
8.53

Math Tasks

GSM8K
8-shot
86.88
92.49
94.16

GSM Symbolic
8-shot
81.32
83.70
75.70

Minerva Math
0-shot, CoT
67.94
80.10
81.32

DeepMind Math
0-shot, CoT
64.64
80.07
81.93

Code Tasks

HumanEval
pass@1
79.27
87.20
89.63

HumanEval+
pass@1
74.39
80.49
85.98

MBPP
pass@1
61.64
82.54
83.33

MBPP+
pass@1
52.91
70.64
71.69

CRUXEval-O
pass@1
40.75
47.63
55.75

BigCodeBench
pass@1
32.19
35.00
38.77

MULTIPLE
pass@1
52.54
60.26
62.31

Eval+ Avg
pass@1
67.05
80.21
82.66

Tool Calling

BFCL v3

60.80
68.27
73.68

Multilingual Tasks

MMMLU
5-shot
57.61
64.84
73.71

INCLUDE
5-shot
52.05
58.89
67.26

MGSM
8-shot
70.00
82.32
71.12

Safety

SALAD-Bench

93.95
95.80
96.41

AttaQ

81.88
81.19
85.76

Tulu3 Safety Eval Avg

66.84
75.57
78.19

Supported languages: English, German, Spanish, French, Japanese, Portuguese, Arabic, Czech, Italian, Korean, Dutch, and Chinese.

Granite 4.1 Comparison with Leading Open‑Source Models

Granite 4.1 delivers competitive instruction‑following and tool‑calling capabilities without relying on long chains of thought. By avoiding extended reasoning traces, it provides predictable latency, stable token usage, and lower operational cost. This makes Granite 4.1 a production‑ready, open‑source choice for enterprise workloads where efficiency, reliability, and cost control are critical.

Granite 4.1-8B vs. Granite 4.0-H-Small (32B-A9B)

A striking result: the Granite 4.1-8B dense model consistently matches or outperforms the previous-generation Granite 4.0-H-Small, a 32B-parameter Mixture-of-Experts model with 9B active parameters.

Figure 13: Granite 4.1-8B (dark blue) vs. Granite 4.0-H-Small 32B-A9B (light blue) across benchmarks. The 8B dense model matches or exceeds the larger MoE model on IFEval, AlpacaEval, MMLU-Pro, BBH, GSM8K, DeepMind-Math, Evalplus, ArenaHard, BFCL V3 and MBPP(+).

Granite 4.1 Model Family Comparison

Figure 14: Comparison across the Granite 4.1 family — 30B, 8B, and 3B models. Scores scale predictably with model size, with the 30B model leading across all benchmarks.

FP8 Quantization

We also released fp8 quantized variants of the Granite 4.1 models, optimized for inference with vLLM. The precision is reduced from 16‑bit to 8‑bit, resulting in approximately a 50% reduction in both disk footprint and GPU memory usage. Quantization is applied only to the weights and activations of linear operators within the transformer blocks using LLM Compressor, while all other layers are preserved at their original precision.

Infrastructure

We trained the Granite 4.1 Language Models on an NVIDIA GB200 NVL72 cluster hosted on CoreWeave:

Intra-rack communication: 72-GPU NVLink domain
Inter-rack communication: Non-blocking, full Fat-Tree NDR 400 Gb/s InfiniBand network
Scale: Thousands of GPUs across the cluster

This infrastructure provides the scalable, high-bandwidth interconnect needed for efficient distributed training at the token volumes required (15T+ tokens across pre-training alone).

Getting Started

Granite 4.1 models are available under the Apache 2.0 license. Here’s how to get started with the 30B instruct model wiht tool calling example:
pip install torch torchvision torchaudio
pip install accelerate
pip install transformers

import torch
from transformers import AutoModelForCausalLM, AutoTokenizer

device = “cuda”
model_path = “ibm-granite/granite-4.1-30b”
tokenizer = AutoTokenizer.from_pretrained(model_path)

model = AutoModelForCausalLM.from_pretrained(model_path, device_map=device)
model.eval()

tools = (
{
“type”: “function”,
“function”: {
“name”: “get_current_weather”,
“description”: “Get the current weather for a specified city.”,
“parameters”: {
“type”: “object”,
“properties”: {
“city”: {
“type”: “string”,
“description”: “Name of the city”
}
},
“required”: (“city”)
}
}
}
)

chat = (
{ “role”: “user”, “content”: “What’s the weather like in London right now?” },
)
chat = tokenizer.apply_chat_template(chat, \
tokenize=False, \
tools=tools, \
add_generation_prompt=True)

input_tokens = tokenizer(chat, return_tensors=”pt”).to(device)

output = model.generate(**input_tokens,
max_new_tokens=100)

output = tokenizer.batch_decode(output)

print(output(0))

Expected Output:
<|start_of_role|>system<|end_of_role|>You are a helpful assistant with access to the following tools. You may call one or more tools to assist with the user query.

You are provided with function signatures within XML tags:

{“type”: “function”, “function”: {“name”: “get_current_weather”, “description”: “Get the current weather for a specified city.”, “parameters”: {“type”: “object”, “properties”: {“city”: {“type”: “string”, “description”: “Name of the city”}}, “required”: (“city”)}}}

For each tool call, return a json object with function name and arguments within XML tags:

{“name”: , “arguments”: }
. If a tool does not exist in the provided list of tools, notify the user that you do not have the ability to fulfill the request.<|end_of_text|>
<|start_of_role|>user<|end_of_role|>What’s the weather like in London right now?<|end_of_text|>
<|start_of_role|>assistant<|end_of_role|>
{“name”: “get_current_weather”, “arguments”: {“city”: “London”}}
<|end_of_text|>

Resources:

Granite 4.1 marks a significant step forward for high‑quality, open‑source language models. By prioritizing data quality and rigor at every stage—from pre‑training curation to supervised fine‑tuning and multi‑stage reinforcement learning—we deliver a substantially improved post‑training pipeline. The result is stronger instruction following, tool use, and conversational performance, showing that carefully trained dense 8B models can rival much larger MoE architectures. We’re excited to see how the community adopts and builds on these models.

---
